Transport tubes for short-circuiting devices

SKU: P 2347-0-00A
Category:

Tubes for the transport of short-circuiting devices  are intended for the optimal transportation of this equipment with vans, providing their protection against rainfall and UV rays. The tube is made of plastic and it is provided with fastening devices on the cross-support bars mounted beforehand on the roof of the van. The tube is provided with an ejection device for short insulating sticks, if they cannot be removed by hand. At one end, the tube is also provided with a mobile lid attached with a protection system against accidental opening and (optionally) with a lock.

The P 2347-0-00A transport tube for sticks and short-circuiting devices can transport simultaneously:

  • two short-circuiting devices for MV overhead lines with self-tightening clamps, Msp-N-AS3x35/10-O/p type
  • one telescopic insulating stick with extended length of 6…9 m

T ransport tube type P 2347-0-00A
Outer diameter (mm) Ø  350
Inner diameter (mm) Ø  300
Total length L (mm) 2650
Utile length (inner) L (mm) 2500
